Facade panels
ISOTEC PARETE PANEL
The panel is fixed to the external surface using mechanical anchors suitable for the structure. The system supports the installation of various types of external cladding, both light and heavy. By creating a ventilated air chamber between the insulation and the cladding, Isotec Parete System helps prevent overheating of the walls in summer and reduces the risk of condensation in winter.
Isotec Parete thicknesses
Isotec Parete panel is available inthe following thicknesses:
60 mm, 80 mm, 100 mm, 120 mm, 140 mm e 160 mm.
The Isotec Parete panel is made of self-extinguishing rigid polyurethane foam.
The Isotec Parete panel is clad on both sides with embossed aluminium sheet.
ISOTEC PARETE STIFFENER HEIGHT: 40 mm
The side ends of the panels are cut into a dovetail shape to ensure continuous insulation.
The Isotec Parete panel is shaped with opposing battens on the longitudinal sides that allow the panels to interlock seamlessly, thus eliminating the risk of thermal bridges.
ISOTEC PARETE BLACK PANEL
This is due to its composition, which includes a PIR polyurethane core and fire-retardant mineral coating on the outer surface. Isotec Parete Black is recommended for applications requiring a specific and higher fire reaction performance.
Isotec Parete Black thicknesses
Isotec Parete Black panel is available in the following thicknesses:
60 mm, 80 mm, 100 mm, 120 mm, 140 mm e 160 mm.
The Isotec Parete Black panel is made of self-extinguishing rigid polyurethane foam.
The Isotec Parete Black panel features embossed aluminium foil on the underside, which makes it impermeable, and a fireproof mineral coating on the top side.
ISOTEC PARETE BLACK STIFFENER HEIGHT: 40 mm
The side ends of the panel are cut into a dovetail shape to ensure continuous insulation.
The Isotec Parete Black panel is shaped with opposing battens on the longitudinal sides that allow the panels to interlock seamlessly, thus eliminating the risk of thermal bridges.
ISOTEC PARETE CATALOGUE
Download the updated and complete pdf version
DECLARATION OF PERFORMANCE
Regulations, essential characteristics and performance of the product
BIM/CAD
